Voltage Regulator Rectifier for Suzuki Boulevard S50 VS800 / S83 VS1400 DR 650 S / SE Intruder VS1400 / VS800 1992-2009
Voltage Regulator Rectifier for Suzuki Boulevard S50 VS800 / S83 VS1400 DR 650 S / SE Intruder VS1400 / VS800 1992-2009
Voltage Regulator Rectifier for Suzuki Boulevard S50 VS800 / S83 VS1400 DR 650 S / SE Intruder VS1400 / VS800 1992-2009
Voltage Regulator Rectifier for Suzuki Boulevard S50 VS800 / S83 VS1400 DR 650 S / SE Intruder VS1400 / VS800 1992-2009
Voltage Regulator Rectifier for Suzuki Boulevard S50 VS800 / S83 VS1400 DR 650 S / SE Intruder VS1400 / VS800 1992-2009
Voltage Regulator Rectifier for Suzuki Boulevard S50 VS800 / S83 VS1400 DR 650 S / SE Intruder VS1400 / VS800 1992-2009
Voltage Regulator Rectifier for Suzuki Boulevard S50 VS800 / S83 VS1400 DR 650 S / SE Intruder VS1400 / VS800 1992-2009
Voltage Regulator Rectifier for Suzuki Boulevard S50 VS800 / S83 VS1400 DR 650 S / SE Intruder VS1400 / VS800 1992-2009
Voltage Regulator Rectifier for Suzuki Boulevard S50 VS800 / S83 VS1400 DR 650 S / SE Intruder VS1400 / VS800 1992-2009
Voltage Regulator Rectifier for Suzuki Boulevard S50 VS800 / S83 VS1400 DR 650 S / SE Intruder VS1400 / VS800 1992-2009

Voltage Regulator Rectifier for Suzuki Boulevard S50 VS800 / S83 VS1400 DR 650 S / SE Intruder VS1400 / VS800 1992-2009

RMSTATOR
SKU: RM30010
In Stock
RMSTATOR

Voltage Regulator Rectifier for Suzuki Boulevard S50 VS800 / S83 VS1400 DR 650 S / SE Intruder VS1400 / VS800 1992-2009

$125.89
This product fits your
Close
FITMENT WARNING:
This product does not fit your
Close
This product is ride specific
Close
Shop By Vehicle

Battery condition is extremely important. No voltage regulator can work correctly with a bad or weak battery. Always fully charge your battery before performing any charging system tests or replacing parts. If there is any doubt, have the battery load tested or replaced.

Read more
Voltage Regulator Rectifier for Suzuki Boulevard S50 VS800 / S83 VS1400 DR 650 S / SE Intruder VS1400 / VS800 1992-2009
Voltage Regulator Rectifier for Suzuki Boulevard S50 VS800 / S83 VS1400 DR 650 S / SE Intruder VS1400 / VS800 1992-2009
$125.89

Details

Brand new voltage regulator rectifier

Please note : There is two possible regulators for the VS 1400 GL Intruder model depending on the year of the vehicule. This regulator fits on 1996-2004 VS 1400 GL Intruder.

  • Direct replacement to your original unit.
  • Plug-and-play, direct fit, easy installation.
  • No assembly required
  • The Quality exceeds the OEM equipment
  • Improved heat sink and charging capabilities
  • Higher grade of electric components.
  • All products shipped are tested

*All item pictures are accurate, if in doubt do not hesitate and compare our item to your original part.

Specifications

Dimensions :
Width : 50mm
Length : 145mm
Height: 25mm
Wires length : 440mm

Other specifications :
Number of plugs : 1
Number of pins : 5
Minimum Charging Voltage: 14.5V +/- 0.5V
Maximum Charging Current: 25A-35A/300W-500W
Open Circuit Voltage: <15V
Operation Temperature: -20⁰ to 85⁰

Interchange Part Nº
  • 32800-12E01
  • 32800-12E00

Installation
Before installing your new regulator/rectifier:
  • Check the AC output of the stator.
  • Replace any burned or corroded connectors on stator and regulator/rectifier
  • Check and repair any melted wiring.
  • Use hi-temp dielectric grease on all connectors.

Warning:

Risk of electric shock. Disconnect the battery before servicing.
Ensure proper installation by a qualified technician to avoid malfunction.
