Stator for Honda CX 500 1978-1981

Name: Stator for Honda CX 500 1978-1981
Brand: RMSTATOR
SKU: RM01055
Price: 229.89 USD
Availability: InStock

RMSTATOR

SKU: RM01055

In Stock

RMSTATOR

Stator for Honda CX 500 1978-1981

$229.89

This product fits your

Close

FITMENT WARNING::

This product does not fit your

Close

This product is ride specific

Close

Shop By Vehicle

Battery condition is extremely important. No stator can work correctly with a bad or weak battery. Always fully charge your battery before performing any charging system tests or replacing parts. If there is any doubt, have the battery load tested or replaced.

Brand new stator

You must re-install your original grommet and the new connector (see picture).
Once your connector and grommet is re-installed, our part becomes a Plug-and-play unit, direct fit, and very easy to install.
Highest grade of lamination materials
Highest grade of copper winding, resistant to 200 degrees Celsius.
All product shipped are tested

We have even included the opposite connector (main harness side) as we know these are often melted/corroded/defective and a major cause for repetitive electrical issues.

*All item pictures are accurate; if in doubt do not hesitate to compare our item to your original part.

Specifications

Dimensions:
Interior diameter : 53 mm
Exterior diameter : 115 mm
Thickness : 16 mm
Length of wires stator to terminals: 875 mm

Other specifications:
Number of wires : 6
Number of terminals : 6

Wire to wire resistance:
Alternator : Between each Black = 0.9 ohms+/-20%
Alternator : Black to Ground =ﾠO.L. ON DISPLAY
Source 1 : White to Blue = 9 ohms+/-20%
Source 2 : Blue to Green = 300 ohms+/-20%

Interchange Part Nº

31120-415-005
31100-415-005

Installation

Download our PDF installation instructions >

Warning:

Risk of electric shock. Disconnect the battery before servicing.
Ensure proper installation by a qualified technician to avoid malfunction.
